R-A4X85/20MI

Maximum Speed	20,000 rpm
Maximum Relative Centrifuge Force (x g)	41,137 g
Maximum Capacity(Rotor)	4 x 85 ml
Item Number:	30314827

Request a Quote ADD TO QUOTE LIST

View All Frontier™ 5000 Rotors Models

Overview
Specs
Accessories
Documents

Overview

Frontier rotors extend the functionality of Frontier centrifuges by increasing the number of tubes of varied types and sizes that can be used in conjunction with each of the centrifuge models. Easy to clean and operate, the rotors are durably constructed to withstand demanding centrifugation.

Applications

Centrifugation Accessory

Display

N/A

Operation

N/A

Communication

N/A

Construction

Aluminum or polypropylene material

Design Features

Easy-installation

Specifications

Maximum Speed	20,000 rpm
Maximum Relative Centrifuge Force (x g)	41,137 g
Maximum Capacity(Rotor)	4 x 85 ml
Tube diameter without adapter	38mm / 85ml
Outer/Inner Radius	92 mm
Rotor Style	Angle
Aerosol tight	Not applicable
Acceleration Time (sec)	60 / 506
Angle	30°
Compatible Models	FC5816R;FC5718R;FC5916R;FC5720R;FC5830R;FC5816;FC5718;FC5916
Deceleration Time (sec)	40 / 1,745
Dimensions	7.4 in (188 mm)
Maximum loading weight	560 g
Multiple Maximum Speeds	No
Net Weight	11.56 lb (5.24 kg)
Working Environment	-4°F – 122°F, 95%RH, non-condensing (Temperature: -20ºC – 50ºC, Humidity: <95%)
