1650-00

Maximum Capacity	610 g
Readability	0.1 g
Pan Size	6 in (152 mm)
Item Number:	80000006

Request a Quote ADD TO QUOTE LIST

View All Triple Beam Dial-O-Gram™ 1600 Series Models

Overview
Specs
Accessories
Documents

Overview

Whether you’re in need of a basic but high quality mechanical balance or you’re looking for the top-of-the-line model that gives you complete flexibility in the classroom, Ohaus has a triple beam for you. No matter which triple beam you choose, rest assured you can count on every Ohaus Triple Beam balance to be accurate and dependable time and time again.

Applications

Weighing

Display

Easy to Read Deep Notched and Tiered Beams and Dial Plates

Operation

N/A

Communication

N/A

Construction

Metal Base and Beam, Stainless Steel Pan

Design Features

Counterbalancing knob for quick zeroing, positive poise positioning for repeatable results, self-aligning beam design, magnetic damping to minimize oscillation and speed weighing.

Specifications

Maximum Capacity	610 g
Readability	0.1 g
Pan Size	6 in (152 mm)
Pan Type	Fixed Pan
Dimensions	17.76 in x 6.62 in x 6.35 in (451 mm x 168 mm x 161 mm) (LxHxW)
Linearity ±	0.1 g
Net Weight	1.7 kg
Power	No Power Required
Tare Range	0g–225g
Units of Measurement	Gram
